Pneumatic Drill Manufacturers in India | Pneumatic Drill Machine in India
Pneumatic Drill Manufacturers, Suppliers in India
Constromine Equipment Private Limited a leading pneumatic drill machine manufacturers and suppliers in India, are providing the new technological pneumatic drill machines. These machines are filled with high powered drilling mechanism and that can be operated using the air instead of electricity or hydraulic systems.
Due to these new technological advanced mechanisms, these machines are used in heavy duty applications such as mining, construction and manufacturing industries for improving its overall durability, efficiency and able to used them into any kind of outer environments. We have used new technological sensors in these machines such as real time monitoring for getting each real time updates of each process. Below, we have listed down its various types, benefits, features and applications also!
Types of our Pneumatic Drill Machine
Being the best pneumatic drill machine manufacturers in India, we are providing the new technological pneumatic drill machine which gives higher performance in every application. Here we have listed down some types such as:
- Heavy-Duty Pneumatic Drills: These drills are primarily used in mining, construction, and infrastructure projects for deep drilling in hard rock and concrete. Energy-efficient motors provide advanced air compression force, and smart sensors help reduce energy consumption.
- DTH (Down-the-Hole) Pneumatic Drills: In these drills, the hammer is located at the bottom of the drill string, delivering a powerful and direct impact. They are used in mining, water well drilling, and oil exploration. Automation and remote control operations enhance safety.
- Air-Leg Drills: These drills are lighter and ergonomically designed for better maneuverability. Adjustable air pressure control increases efficiency in varying rock conditions. They are highly applicable in underground mining and tunneling.
- Stoper Drills: These drills are designed for vertical and overhead drilling. Hydraulic-assisted technology reduces air consumption and increases power output. Auto-jamming technology ensures smooth operation in complex tasks and provides real-time updates.
Technical Specifications of our Pneumatic Drilling Machine
We have given below a technical sheet of our pneumatic drilling machine which clarifies the important technical information about the machine such as:
| Specification | Heavy-Duty Pneumatic Drills | DTH (Down-the-Hole) Pneumatic Drills | Air-Leg Drills | Stoper Drills |
|---|---|---|---|---|
| Application | Mining, Construction, Quarrying | Deep-hole Drilling, Oil & Gas, Water Wells | Underground Mining, Tunneling | Overhead Drilling, Roof Bolting |
| Drilling Depth (m) | 10 - 50 | 50 - 400 | 5 - 30 | 2 - 15 |
| Drilling Diameter (mm) | 32 - 90 | 90 - 300 | 28 - 45 | 25 - 42 |
| Operating Air Pressure (bar/psi) | 5 - 7 (72 - 100 psi) | 7 - 30 (100 - 450 psi) | 4 - 6 (58 - 87 psi) | 4 - 6 (58 - 87 psi) |
| Impact Frequency (bpm) | 1,500 - 3,000 | 500 - 1,500 | 1,200 - 2,500 | 1,000 - 2,200 |
| Rotation Speed (rpm) | 200 - 800 | 80 - 400 | 250 - 750 | 300 - 700 |
| Air Consumption (m³/min) | 1.5 - 6.5 | 2.5 - 25 | 1.2 - 4.5 | 1.0 - 3.5 |
| Drill Bit Type | Tungsten Carbide, Cross Bit | DTH Hammer Bit (Concave, Convex, Flat Face) | Tapered Button, Cross Bits | Plug Bits, Conical Bits |
| Drill Bit Life (hrs) | 80 - 200 | 150 - 400 | 50 - 150 | 40 - 120 |
| Machine Weight (kg) | 25 - 45 | 80 - 250 | 12 - 30 | 10 - 25 |
| Drill Rod Length (mm) | 500 - 3,000 | 1,000 - 6,000 | 400 - 2,500 | 300 - 1,500 |
| Automation Level | 30 - 50% (Semi-Automatic) | 50 - 100% (Semi to Fully Automatic) | 20 - 50% (Manual & Semi-Auto) | 10 - 40% (Manual & Semi-Auto) |
| Vibration Reduction (%) | 40 - 60 | 50 - 70 | 30 - 50 | 20 - 40 |
| Noise Level (dB) | 95 - 110 | 90 - 115 | 85 - 105 | 80 - 100 |
| Cooling System | Air Cooling, Optional Water Mist | Air-Water Cooling System | Air Cooling | Air Cooling |
Features and Benefits of our Pneumatic Drill Machine
One of the former pneumatic drilling machine suppliers in India, our all types of machines are made with latest technological manufacturing methods and gives multiple benefits such as:
High Power-to-Weight Ratio
- Our new technological pneumatic drill machines offer a high power output because of their lightweight design, making them easy to handle.
- This function can reduces the unwanted energy of the operators and also increase the productivity, especially in extended drilling tasks.
Continuous Operation Capability
- As compared to the traditional electric drills, pneumatic drills can run continuously without overheating.
- This makes them ideal for industrial applications where prolonged usage is required.
Explosion-Proof Design
- With the new technological innovation, we have used more safety standards in these machines for more safety in hazardous environments such as oil refineries and chemical plants.
- This ensures worker safety while reducing the risk of workplace accidents.
Variable Speed Control
- The use of automatic and adjustable speed settings is highly used to match different materials and drilling requirements.
- This allows for greater precision and prevents damage to delicate surfaces.
Lightweight and Ergonomic Design
- Pneumatic drills are designed to be compact and lightweight and this can makes them easier to maneuver in tight spaces.
- Their ergonomic grip reduces strain on the user's hands, improving comfort and efficiency.
Applications of our Pneumatic Drilling Machine
As a former pneumatic drilling machine manufactures in India, our all types of machines are highly used in multiple types of applications such as:
- Construction site concrete drilling and surface breaking
- Road maintenance for asphalt and concrete removal
- Underground mining operations for rock excavation
- Shipyard metal surface cleaning and preparation
- Pipeline installation for precise hole drilling
- Quarrying industry for stone cutting operations
- Automotive repair for body panel removal
- Bridge maintenance involving bolt tightening tasks
- Demolition of old structures and buildings
- Rail track maintenance and repair operations
Being the best pneumatic drilling machine manufacturers and suppliers in India, we as Constromine Equipment Private Limited are providing the new technological pneumatic drill machine. This machine is commonly known for its rugged design and used for working in complex and heavy duty tasks. We have used multiple types’ new technological innovation in these machines for getting more output and smooth working flow. For more information about our pneumatic drilling machine, contact us today!
